Background Story
R4's unique design language hails to such elements as cyberpunk, mecha, and space opera. Clear-cut powerful geometric lines cross to form the silhouette of a living, breathing audio machine, with the offset hatch design on the back adding to the motif of a retro classic set in the distant future.
DESIGN CONCEPT
A sturdy lanyard lug coupled with the graffiti-designed lanyard makes for a striking appearance as well as practical usability in outdoor / active scenarios--the quest for an appealing, youthful outlook follows practical considerations to yield a form that is at once instantly recognizable and suitable for a wide audience.
4-Way ES9018C2M DAC Array
Sporting an unprecedent-for-the-sector set of four separate ES9018C2M DAC chips in a matched array, the R4 has indubitable fidelity in digital-analog conversion, yielding higher resolution and wider dynamic range from any source file, bringing smoother, purer sound. Supporting native playback of DSD up to 256 and PCM up to 32bit/768kHz.
PCM / DSD Dual Customized Conversion Pathways
Separate conversion pathways for PCM and DSD conversion realized for the first time in portable DAPs; separate individually configured / designed DAC chips, LPF and power supplies for PCM and DSD conversion;
Device firmware automatically routes PCM and DSD each to their dedicated pathways. DSD channel more effectively rejects high ultrasonic noise, bringing substantially better listening experience for DSD;
Flagship-Grade Processing Power
Utilizing the Snapdragon 665 SoC with its 8-core CPU, the R4 runs multiple apps smoothly and speedily completes complex music library and audio processing tasks alike, bringing smooth operation and a high quality usage and listening experience to users.
Open Android 12 System
Compatible with all streaming platforms Being based on Android 12 with its excellent compatibility and stability, all mainstream apps and especially all streaming apps run smoothly. Further benefitting from HiBy's software development prowess, timely system updates and function upgrades will bring users a customized, intelligent and intuitive experience in the R4
Class A Amplification for Bountiful Drive Power
- 4 Pieces OPA1652
- 2 Pieces OPA1612
- 16 Pieces Transistor
Utilizing widely acclaimed class-A amplification throughout, the amplifier is composed of four OPA1652, 2 OPA1612 and 16 transistor, and has zero crossover distortion for instant transient response; output scales up to 525mW/322, and distortion can be as little as 0.0005%, yielding a fine sense of power from music as well as exquisite detail.
Flagship-Grade Audio Componentry
28 High-precision tantalum capacitors
Bring finer power supply ripple rejection for blacker background and greater detail.
3.5mm SE And + 4.4mm Balanced
Audio ports make for a wide range of suitable usage Almost any earphones can be plugged in and the device is well tuned for popular music.
FPGA Clock Algorithm
DUAL INDEPENDENT CRYSTAL OSCILLATORS
Utilizing dual independent audiophile-grade crystal oscillators at 45.158MHz and 49.152MHz effectively reduces phase noise and jitter, providing provides high precision timing for all audio events in your music.
Large Screen, High Res, Stop Press (720 x 1080 Resolution)
Large hi-res 4.7" Sharp LCD screen with 24 bits / 16.7 million colours, see the music world through a wider clearer lens.
Long Run Time, High Battery Capacity
4500mAh battery yielding up to 11 hours run time on 3.5mm SE output, as well as long run time under heavy screen / CPU / wireless use.
The Ever-reliable HiBy OS
The HiBy OS is an in-house developed system architecture developed by HiBy targeting professional HiFi audio equipment. Optimized / novel components include system core, decoding system, audio DSP algorithms, media library management, external drivers / plugins etc. optimizing the player for lossless hi-res audio from the ground up. HiBy OS is synonymous with audio quality, flexibility and reliability.
True Systemwide Bitperfect Audio
Made for professional audio, bypasses Android sample rate conversion systemwide. Enjoy hi-res music, including from streaming apps such as Apple Music!
HiByCast Systemwide Remote Control Via HiBy Cast
Control all aspects of the device remotely via WiFi on any supported smartphone or tablet. Supports operation of HiBy Music app as well as third party apps.
High Res Audio Formats Support
DSD256 and PCM 32bit / 768kHz
16x unfold of MQA files, giving master-tape quality audio re-constitution, richer replay of the sound as intended-it's a take-you-to-the-concert/ studio experience!
MQA (Master Quality Authenticated) is an award-winning technology that captures and reproduces the sound of the original studio master in a file that's small enough to stream and download. HiBy is collaborating with MQA to deliver truly original sound quality to listeners.
User-Defined Fn Toggle
Unique physical Fn toggle supports custom functions such as button lock and screen flip.
Bluetooth 5.0
Bidirectional Bluetooth supports multiple hi-res Bluetooth codecs such as UAT, LDAC, aptX, aptX HD, AAC, SBC etc. 2.4GHz/5GHz dual band WiFi with stable connection for always-online music.
UAT (Ultra Audio Transmission) is HiBy's in-house developed all-new Bluetooth audio transmission codec. Supporting an industry-highest 192kHz transmission sample rate and up to 1.2Mbps Bluetooth bandwidth, this also can optimize its transmission characteristics according to different music genres, for the highest of audio fidelity from wireless!
